Sonic PIPE +CO
Sonic Pipe+ CO.jpgSonic PIPE +CO
Acoustic Cylinder Luminaire
- Architectural acoustic luminaire with direct lighting distribution.
- Light source: COB LED.
- High-efficiency integral reflector combined with opal lens insert provides excellent lighting distribution.
- Extruded aluminum body comes with a black or white finish.
- Removable fin-shaped Eco-Felt Baffles are attached to the top and face plate.
- Available in two standard sizes with various baffle shapes.
- Class 1 fire rated with 0.7 Noise Reduction Coefficient/1” Acoustic.
- LED spot is rated for 60,000 hrs. L70 with +90 CRI.
- Suitable for suspended installations.
- Custom finishes and modifications are available.
- ED luminaires are certified to CSA and UL standards
Resources
Materials
- Aluminum
- Felt
Mounting
- Pendant
- Suspended
Shape
- Bell
- Curve
Color / Finish
- Black
- White
Lumens
- 930
- 1200
- 1900
Watts
- 10
- 15
- 20
Beam Angle
- 25
- 45
- 60
CCT
- 3000K
- 3500K
- 4000K
CRI
- 90
Circuit
- Single
Dimensions
- L: 24 In. W: 24 In. H: 16 In.
Dimming Protocol
- 0-10 V
Dimming Range
- 1%
- 10%
Distribution
- Diffuse
Lamp Life
- 60000
Lamp Source
- LED
Listings
- cULus
Ratings & Compliance
- DLC
- Declare
- Made in Canada
Special Programs
- Rapid Response
Static LED Color
- Static
Voltage
- 120 V
- 277 V
Warranty
- 1 yr
Lighting
- Lit
